Studiomaster Club XS 16+
Studiomaster Club XS+ 16+ – 16-Channel Compact Mixer
The Studiomaster Club XS+ 16+ is a versatile and compact mixer, building on the Club XS series with added features for enhanced control. It’s designed for live sound reinforcement and recording, offering 12 mic channels, stereo channels, DSP effects, and a USB/SD media player.
Key Features
16 Inputs: 12 mic channels and 2 stereo channels.
Mic Channels:
3-band EQ
3 Auxiliaries
Balanced mic/line sockets
Compressor control
High-pass filter
Channel Mute
Listen (PFL) switch
Stereo Channels:
2-band EQ
2 Auxiliaries
Main Outputs: Balanced XLR connectors.
Auxiliary and Control Room Outputs: 1/4″ jack outputs.
2-Track Inputs/Outputs: RCA phono connectors for record and playback.
USB/SD Card Facility: For stereo recording and playback.
Built-in MP3 Player: For convenient playback.
Bluetooth Playback: Wireless audio streaming from compatible devices.
16 Programme DSP Effects Unit: High-quality digital effects.
+48V Phantom Power: Switchable phantom power on all mic channels.
60mm Smooth Faders: For precise level control.
Internal Switchmode Power Supply: Robust and quiet operation.
Extra Monitor Busses: (Compared to other Club XS models)
PFL on All Channels: (Compared to other Club XS models)
Footswitch Socket: For DSP on/off control.
Technical Specifications
Inputs: 12 Mic, 2 Stereo
EQ: 3-band (Mic), 2-band (Stereo)
Auxiliaries: 3
Effects: 16 DSP programs
Media: USB/SD
Bluetooth: Yes
Outputs: XLR (Main), 1/4″ Jack (Aux, Control Room), RCA (2-Track)
What’s in the box
Studiomaster Club XS+ 16+ Mixer
Power cable
User manual
