TP-Link TL-WR841N – Fast Ethernet Single-band (2.4 GHz) Wi-Fi 4 Wireless Router
300Mbps Wireless N Speed – Fast Download Speed
TP-Link’s TL-WR841N is a high speed solution that is compatible with IEEE 802.11 b/g/n. Based on 802.11n technology, TL-WR841N gives users wireless performance at up to 300Mbps, which can meet your most demanding home networking needs, such as HD streaming, online gaming and large files downloading.
Access Point Mode
Transform your existing wired network to a wireless one.
Range Extender Mode
Boost the existing wireless coverage in your room.
WISP Mode
Connect to the ISP network wirelessly in areas without wired service.
Easy Setup and Use
Set up the TL-WR841N in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and access control.
| Wireless LAN features | |
|---|---|
| WLAN data transfer rates supported | 11,54,300 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 300 Mbit/s |
| Wi-Fi band | Single-band (2.4 GHz) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN features | |
| Ethernet WAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| DSL features | |
| DSL WAN | No |
| xDSL connection | No |
| Mobile network | |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| Mobile network connection | No |
| 3G | No |
| 4G | No |
| Protocols | |
| DMZ support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| Management features | |
| Universal Plug and Play (UPnP) | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Security | |
| VPN support | PPTP, L2TP, IPSec |
| Security algorithms | 128-bit WEP, 152-bit WEP, 64-bit WEP, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS |
| MAC address filtering | Yes |
| Firewall security | SPI |
| Firewall | Yes |
| DoS attack prevention | Yes |
| DMZ support | Yes |
| Filtering | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Performance | |
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported | macOS |
| Linux operating systems supported | Yes |
| Memory card slot(s) | No |
| Weight & dimensions | |
| Package width | 288 mm |
| Package weight | 520 g |
| Package height | 86 mm |
| Package depth | 202 mm |
| Width | 174 mm |
| Weight | 700 g |
| Height | 28 mm |
| Depth | 119 mm |
| Certificates | |
| Certification | CE, FCC, RoHS |
| WAN connection | |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| Network | |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| VPN support | PPTP, L2TP, IPSec |
| Port forwarding | Yes |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u |
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| Port triggering | Yes |
| VPN Passthrough | Yes |
| Dynamic DNS (DDNS) | Yes |
| Ports & interfaces | |
| USB port | No |
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Yes |
| Memory card slot(s) | No |
| Design | |
| Product type | Tabletop router |
| On/off switch | Yes |
| LED indicators | Power, Status, WLAN |
| Product colour | Black, White |
| Software | |
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported | macOS |
| Linux operating systems supported | Yes |
| Packaging content | |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Antenna | |
| Antenna design | External |
| Receive power | 270M: -70dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -87dBm@8% PER 6M: -90dBm@10% PER 1M: -98dBm@8% PER |
| Detachable antenna(s) | No |
| Antennas quantity | 2 |
| Antenna gain level (max) | 5 dBi |
| Transmit power | 20 dBmW |
| Features | |
| Certification | CE, FCC, RoHS |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power source type | DC |
| Power consumption (typical) | 8 W |
| Output voltage | 9 V |
| Output current | 0.6 A |
| Operational conditions | |
| Storage temperature (T-T) | -40 – 70 °C |
| Storage relative humidity (H-H) | 5 – 90% |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| System requirements | |
| Windows operating systems supported | Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported | macOS |
| Linux operating systems supported | Yes |
| Packaging data | |
| Quick start guide | Yes |
| Package width | 288 mm |
| Package weight | 520 g |
| Package height | 86 mm |
| Package depth | 202 mm |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| xDSL connection | No |
| Mobile network connection | No |
| WLAN data transfer rates supported | 11,54,300 Mbit/s |
| Rack mounting | No |
| Input current | 0.6 A |
| Frequency band | 2.4 GHz |
| Filtering description | IP, MAC, URL |
