iiyama ProLite TF1633MSC-B1 – 39.6 cm (15.6″) – 1920 x 1080 pixels Full HD Touchscreen Monitor
PROLITE TF1633MSC-B1 15.6″ PCAP 10 points multi-touch open frame monitor with edge-to-edge glass and IPS panel technology
The ProLite TF1633MSC-B1 uses projective capacitive touch technology, built into an eye catching bezel with edge-to-edge glass. The screen guarantees high durability, scratch-resistance, clarity and a perfect picture performance. Featuring IPS Panel Technology and Full HD (1920×1080) resolution, it offers natural, highly accurate colours and wide viewing angles. The integrated cable management system hides all the cables. In addition to the superb image quality, the screen comes with an IP54 rating, which means the screen and bezel is dust and water resistant from the front. A perfect solution for kiosk integrators and Instore Retail.
| Display |
| DDC/CI |
Yes |
| Viewable size, vertical |
19.4 cm |
| Viewable size, horizontal |
34.4 cm |
| Horizontal scan range |
30 – 68 kHz |
| Pixel pitch |
0.179 x 0.179 mm |
| Display number of colours |
16.7 million colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Maximum refresh rate |
60 Hz |
| Contrast ratio (typical) |
1000:1 |
| Screen shape |
Flat |
| Response time |
5 ms |
| Display brightness (typical) |
385 cd/m² |
| Touchscreen technology |
Projected capacitive system |
| Panel type |
IPS |
| HD type |
Full HD |
| Touchscreen |
Yes |
| Native aspect ratio |
16:9 |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
39.6 cm (15.6″) |
| Performance |
| Low Blue Light technology |
Yes |
| AMD FreeSync |
No |
| Multimedia |
| RMS rated power |
4 W |
| Number of speakers |
2 |
| Built-in camera |
No |
| Built-in speaker(s) |
Yes |
| Design |
| Certification |
CE, TÜV-Bauart, EAC, RoHS, ErP, WEEE, REACH, UKCA |
| International Protection (IP) code |
IP54 |
| Product colour |
Black |
| Market positioning |
Home |
| Ports & interfaces |
| DisplayPorts quantity |
1 |
| HDMI |
Yes |
| Built-in USB hub |
Yes |
| Ergonomics |
| Number of OSD languages |
12 |
| On Screen Display (OSD) languages |
Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Italian, Japanese, Polish, Portuguese, Russian |
| On Screen Display (OSD) |
Yes |
| Tilt angle range |
90 – 5° |
| Height adjustment |
No |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Cable management |
Yes |
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Power |
| Energy efficiency scale |
A to G |
| Power supply type |
External |
| Power consumption (off) |
0.5 W |
| Power consumption (standby) |
8 W |
| Power consumption (typical) |
12 W |
| Energy consumption (SDR) per 1000 hours |
8 kWh |
| Energy efficiency class (SDR) |
C |
| Packaging content |
| Quick start guide |
Yes |
| Power adapter included |
Yes |
| Cables included |
AC, HDMI, USB |
| Weight & dimensions |
| Weight (without stand) |
2 kg |
| Height (without stand) |
246.5 mm |
| Depth (without stand) |
45.5 mm |
| Width (without stand) |
389 mm |
| Packaging data |
| Package type |
Box |
| Package weight |
3.9 kg |
| Package height |
343 mm |
| Package depth |
169 mm |
| Package width |
475 mm |
| Sustainability |
| European Product Registry for Energy Labelling (EPREL) code |
1629699 |
| General |
| Product Family |
ProLite |
