FBT HiMaxX 60A
With the new HiMaxX series FBT establishes a reference point on the scenario of 12 and 15 enclosures in polypropylene for sound reinforcement introducing performance and technical content of a standard unthinkable up until now. FBT HiMaxX takes its place alongside the FBTMaxX series exalting all the technical features.Ā The study of a new cabinet in polypropylene the use of a switch mode power supply and high efficiency power amplifiers and the redesign of the loudspeakers were the activities of the FBT RD team aimed at maximizing the power weight ratio. This series comprises three models; two 2-way full-range enclosures in polypropylene HiMaxX 40 (12+1) and HiMaxX 60 (15+1.4) plus a compact Ā18 bandpass SUB in birch plywood (HiMaxX 100Sa). Compact and light weight HiMaxX brilliantly solve all the most demanding requests from buffs musicians and professionals looking for powerful versatile and very high quality loudspeaker enclosures. Ideal for live and sound reinforcement applications requiring ease of transport they are also suited to fixed installations thanks to the cabinets format and optional accessories. A powerful dynamic design for aggressive clean-cut lines. ĀA sturdy light-weight box that ensures great versatility and is ready for installation thanks to its special mounting points and optional accessories. The asymmetrical design enables the enclosures to be used as stage monitors. A specially designed control panel ensures ease of use and intuitive control. Micline input auxiliary stereo input with (HiMaxX 40a) 3-band EQ ground-lift diagnostic LED. Loudspeaker totally redesigned in collaboration with BC. FBT studied and designed a special chassis a more efficient ventilation circuit with a consequent reduction of 2dB power compression a considerably stiffer cone to improve reliability and distortion and an even more powerful neodymium magnet to increase control and efficiency. The voice coil has a diameter of 75 mm (3) for higher power handling and reliability. Thanks to the use of a shorting copper cap high frequencies are even more dynamic and crystal-clear. The development of the innovative amplifier is the result of years of research by the FBT RD labs. It manages to combine the contrasting features of lightness high power efficiency and reliability using the very latest technology. A switch mode power supply to reduce the weight and increase the power output velocity a very high performance PWM amplifier for the low frequencies to maximize the power fed out with minimum heat dissipation. A Class G amplifier for the high frequencies enables to achieve the audio quality of a Class A with a much higher output. The silent preamplifier manufactured with SMD technology has the job of handling the equalization 24dBoct Ācrossover sophisticated protections limiter and the commands of the control panel. 2-way bi-amplified in Bass- Reflex design. BC custom designed 380 mm (15) neodymium woofer with 75 mm (3) voice coil. BC 36 mm (1.4) compression driver with 64 mm (2.5) voice coil. 700Wrms PWM LF power amplifier. 200Wrms Class G HF power amplifier. Switch mode power supply for an excellent ratio weightpower. Analog signal processor limiter Completely redesigned control panel with: XLR Input and XLR Link. Gain and Volume functions in a single potentiometer to improve user friendliness improving the dynamic range and input signalnoise ratio. 3-band EQ (Bass Mid High). Ground-lift. Diagnostic LED. 90ĀH x 60ĀV constant directivity horn. 4 x M10 anchoring points 35 mm (1.38) top-hat for speaker stand placement and wall bracket mount flange 2 integrated carrying handles.
