Electro-Voice ELX200-15P
Electro-Voice ELX200-15P
The Electro-Voice ELX200-15P is a powerful and versatile active PA speaker designed for DJs, musicians, and live sound applications. Featuring a 15-inch EVS-15M woofer and a 1-inch DH-1L titanium compression driver, this 2-way loudspeaker delivers exceptional audio clarity with robust bass and a maximum SPL of 132 dB, powered by a high-efficiency 1200W Class-D amplifier. The integrated QuickSmartDSP offers intuitive control with four presets (Music, Live, Speech, Club), a three-band EQ, and five user-programmable settings, ensuring optimised sound for any venue. Its lightweight, durable polypropylene enclosure includes three M10 suspension points, integrated pole mounts, and convenient handles for simple transport and setup. Ideal for both portable and installed use, the ELX200-15P combines professional-grade performance with portability, making it a top choice for medium-sized venues and events.
Key features:
- Product Name: Electro-Voice ELX200-15P Active PA Speaker
- Amplifier Power: 1200W Class-D amplifier
- Maximum SPL: 132 dB peak
- Frequency Response: 48 Hz – 19 kHz (-10 dB); 55 Hz – 16 kHz (-3 dB)
- Coverage Pattern: 90° horizontal x 60° vertical
- Transducers:
- 15″ EVS-15M woofer
- 1″ DH-1L titanium compression driver
- Crossover Frequency: 1600 Hz
- Inputs:
- 2x XLR/TRS combo jacks (mic/line level)
- 1x stereo RCA input
- Outputs: 1x XLR link output
- Enclosure: Lightweight polypropylene with internal reinforcement
- Mounting:
- 3x M10 threaded suspension points
- Integrated 35mm pole mount
- Power Supply: 100-240V, 50-60 Hz, 1.8A
- Dimensions: 710 mm x 423 mm x 384 mm (27.95″ x 16.65″ x 15.12″)
- Weight: 18.9 kg (41.7 lbs)
Key features
- QuickSmartDSP: Best-in-class processing with single-knob control and LCD interface for easy setup and optimization:
- 4 presets (Music, Live, Speech, Club)
- Sub/top system-match crossovers
- 3-band EQ
- 5 user-programmable presets
- Visual limiter status, input level control, and meters
- Bluetooth Connectivity: QuickSmart Mobile app for wireless control and monitoring of up to 6 ELX200 speakers (available in select countries)
- SST Waveguide: EV-patented Signal Synchronised Transducers design for precise, consistent coverage with minimal distortion
- Portability: Lightweight enclosure with three ergonomic handles for easy lifting and transport
- Durability: Polypropylene enclosure with steel grille, tested for over 500 hours of abuse and endurance
Highlights
- High-Performance Audio: Delivers up to 132 dB SPL with clear mids, highs, and defined bass, ideal for medium-sized venues.
- Versatile Applications: Perfect for DJs, bands, musicians, and live sound reinforcement, with flexible mounting options.
- User-Friendly: Intuitive DSP and app control simplify sound tuning, even for beginners.
- Portable Powerhouse: Combines lightweight design with professional-grade output and durability.
Product-related questions and answers:
Q: What kind of venues is the ELX200-15P best suited for?
A: It’s ideal for small to medium venues like bars, clubs, or outdoor events, delivering up to 132 dB SPL with wide coverage for audiences of varying sizes.
Q: Can I use this speaker without a subwoofer?
A: Yes, the 15″ woofer provides solid bass down to 48 Hz, making it effective standalone, though pairing with a subwoofer (e.g., ELX200-18SP) enhances low-end for larger events.
Q: How easy is it to set up and adjust the sound?
A: Very easy, QuickSmartDSP offers presets and EQ adjustments via a single knob and LCD, plus the Bluetooth app allows wireless tweaking from anywhere in the venue.
Q: Is the Bluetooth app necessary to use the speaker?
A: No, the onboard DSP controls are fully functional without the app, which is an optional convenience for remote adjustments.
Q: How durable is the ELX200-15P for frequent transport?
A: It’s built to last, with a lightweight yet tough polypropylene enclosure and steel grille, rigorously tested for over 500 hours of abuse.
Q: Can I connect multiple ELX200-15P speakers together?
A: Yes, the XLR link output allows daisy-chaining, and the app can control up to 6 units simultaneously for larger setups.
Q: Is it suitable for outdoor use?
A: Yes, for temporary outdoor gigs, but it’s not weatherproof, protect it from rain or extreme conditions.
Q: What’s the warranty like?
A: Electro-Voice typically offers a 3-year warranty on powered speakers, though you should confirm with DJKit for exact terms.
Q: How does it handle high volumes without distortion?
A: The 1200W Class-D amp and DSP limiter ensure clean, distortion-free sound even at peak SPLs.
Q: Are accessories included, like cables or a pole?
A: The speaker comes standalone; cables, poles, or covers are sold separately, though some retailers may offer bundles.
