Chieftec CW-01B-OP Tower in Black
Chieftec CW-01B-OP, Workstation Case, ATX
The CW-01B-OP is Chieftec’s interpretation of a high-performance workstation case, providing high functional flexibility with external and internal drives and diverse cooling options. Preinstalled dust filters guarantee you a dust-free system. Featuring a modern, yet timeless, design combining brushed aluminum and filtered mesh, the Chieftec CW-01B-OP provides great airflow for optimal workstation performance.
| Design |
| Maximum graphics card length |
41 cm |
| Maximum CPU cooler height |
16.5 cm |
| Anti-dust filter |
Yes |
| Illumination |
No |
| Side window |
No |
| Number of expansion slots |
7 |
| Number of external 5.25″ bays |
3 |
| Number of internal 3.5″ bays |
7 |
| Number of 2.5″ bays |
7 |
| Number of 3.5″ bays |
7 |
| Number of 5.25″ bays |
3 |
| Supported motherboard form factors |
ATX, micro ATX, Mini-ITX |
| Product colour |
Black |
| Material |
SPCC |
| Type |
PC |
| Form factor |
Tower |
| Power supply |
| Supported power supply form factors |
ATX |
| Power supply location |
Bottom |
| Power supply included |
No |
| Ports & interfaces |
| Audio output |
Yes |
| Audio input |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Cooling |
| Top radiator sizes supported |
280 mm |
| Bottom fans diameters supported |
120,140 mm |
| Number of bottom fans supported (max) |
1 |
| Top fans diameters supported |
120,140 mm |
| Number of top fans supported (max) |
2 |
| Side fans diameters supported |
120 mm |
| Number of side fans supported (max) |
1 |
| Front fans diameters supported |
120 mm |
| Number of front fans supported (max) |
2 |
| Storage |
| HDD/SSD combo cage |
Yes |
| Supported HDD sizes |
2.5,3.5″ |
| Weight & dimensions |
| Material thickness |
0.7 mm |
| Weight |
6.8 kg |
| Height |
471 mm |
| Depth |
490 mm |
| Width |
210 mm |
| Packaging data |
| Package weight |
7.8 kg |
| Logistics data |
| Harmonized System (HS) code |
84733080 |
