CHERRY KC 1000 SC keyboard USB QWERTZ German Grey
KC 1000 SC, USB, 1.8 m
– Smart, wired security keyboard with integrated chip card terminal.
– Secure PIN entry.
– PC/SC smartcard reader.
– Protocols: T=0, T=1, S=8, S=9, S=10.
– EMV 2000 Level 1 approved.
– CCID compatible.
– Reading/writing ISO 7816 compliant smartcards.
– Supports firmware update in the field (through flash controller).
– Flat design, low smart card contacting unit.
– Satisfies requirements defined by FIPS-201 (approval process ongoing).
– German version with DIN/GS compliant layout.
– Driver support for Windows/MacOS-X/Linux.
– One-handed operation of smart card module.
– German version complies with BGI 650 guidance for ergonomics.
| Keyboard |
| Certification |
cURus, VDE GS, c-tick, VCCI, CE, FCC |
| Smart card reader |
Yes |
| Fingerprint reader |
No |
| Purpose |
PC/Server |
| USB hub |
No |
| Connectivity technology |
Wired |
| Number of hot keys |
4 |
| Hot keys |
Yes |
| Windows keys |
Yes |
| Keyboard keys operating life |
10 million characters |
| Keyboard number of keys |
105 |
| Numeric keypad |
Yes |
| Keyboard form factor |
Full-size (100%) |
| Pointing device |
No |
| Keyboard language |
German |
| Keyboard layout |
QWERTZ |
| Device interface |
USB |
| Recommended usage |
Office |
| Design |
| Surface coloration |
Monochromatic |
| Product colour |
Grey |
| Wrist rest |
No |
| Keyboard style |
Straight |
| Backlight |
No |
| Features |
| Cable length |
1.8 m |
| Power |
| Power consumption |
100 mA |
| Power source type |
USB |
| System requirements |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Operational conditions |
| Storage temperature (T-T) |
-20 – 65 °C |
| Operating temperature (T-T) |
0 – 50 °C |
| Weight & dimensions |
| Keyboard weight |
840 g |
| Keyboard dimensions (WxDxH) |
458 x 188 x 46 mm |
| Packaging data |
| Package type |
Box |
| Package weight |
1.15 kg |
| Package height |
55 mm |
| Package depth |
232 mm |
| Package width |
472 mm |
| User guide |
Yes |
| Logistics data |
| Products per master (outer) case |
56 pc(s) |
| Harmonized System (HS) code |
84716060 |
| Other features |
| Internal |
No |
