Advantech AIM-68 (4G LTE) – 25.6 cm (10.1″) – 64 GB – 4 GB – Wi-Fi 5 – Windows 10 IoT Enterprise – Black
10.1″ 800 nits, LPDDR3 4 GB, 64 GB, NFC, Wi-Fi/BT, WI-FI Pass Through, LTE+GPS, 5MP & 2MP, Win 10 IoT Enterprise
| Display |
| HD type |
Full HD |
| Touchscreen type |
Capacitive |
| Touch technology |
Multi-touch |
| Display glass type |
Corning Glass |
| Display brightness |
800 cd/m² |
| Display technology |
LCD |
| Display resolution |
1200 x 1920 pixels |
| Display diagonal |
25.6 cm (10.1″) |
| Processor |
| Processor threads |
4 |
| Memory |
| Maximum internal memory |
8 GB |
| Internal memory type |
LPDDR3-SDRAM |
| Internal memory |
4 GB |
| Storage |
| Storage media |
eMMC |
| Compatible memory cards |
MicroSD (TransFlash) |
| Card reader integrated |
Yes |
| Internal storage capacity |
64 GB |
| Graphics |
| Graphics card |
HD Graphics 5000 |
| Graphics card family |
Intel |
| Audio |
| Built-in microphone |
Yes |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Camera |
| Front camera resolution (numeric) |
2 MP |
| Front camera |
Yes |
| Flash type |
LED |
| Rear camera flash |
Yes |
| Auto focus |
Yes |
| Rear camera resolution (numeric) |
5 MP |
| Rear camera |
Yes |
| Rear camera type |
Single camera |
| Network |
| Ethernet LAN |
No |
| Near Field Communication (NFC) |
Yes |
| WWAN |
Installed |
| Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Bluetooth version |
4.1 |
| Bluetooth |
Yes |
| 4G standard |
LTE |
| Mobile network generation |
4G |
| Mobile network connection |
Yes |
| Ports & interfaces |
| Headphone out |
Yes |
| Microphone in |
Yes |
| Combo headphone/mic port |
Yes |
| Micro HDMI ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Design |
| Certification |
FCC ID, TELEC, NCC, SRRC, RCMUL, CB, LVD + Energy Star 6.1, CE, FCC, IC, VCCI, BSMI |
| International Protection (IP) code |
IP65 |
| Device type |
Mobile tablet |
| Product colour |
Black |
| Form factor |
Slate |
| Performance |
| Electronic compass |
Yes |
| Ambient light sensor |
Yes |
| Accelerometer |
Yes |
| GPS (satellite) |
Yes |
| Assisted GPS (A-GPS) |
Yes |
| GLONASS |
Yes |
| BeiDou |
Yes |
| Position location |
Yes |
| Software |
| Operating system installed |
Windows 10 IoT Enterprise |
| Platform |
Windows |
| Battery |
| Battery life (max) |
5.5 h |
| Battery recharge time |
3 h |
| Battery voltage |
10.8 V |
| Battery capacity |
26 Wh |
| Battery capacity |
2400 mAh |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Power |
| AC adapter output voltage |
19 V |
| AC adapter frequency |
50 – 60 Hz |
| AC adapter input voltage |
100 – 240 V |
| AC adapter power |
65 W |
| Weight & dimensions |
| Weight |
980 g |
| Height |
180.1 mm |
| Depth |
18.3 mm |
| Width |
280 mm |
| Packaging content |
| AC adapter included |
Yes |
| Operational conditions |
| Non-operating altitude |
0 – 12192 m |
| Operating altitude |
0 – 3048 m |
| Storage relative humidity (H-H) |
10 – 95% |
| Operating relative humidity (H-H) |
10 – 90% |
| Storage temperature (T-T) |
-20 – 70 °C |
| Operating temperature (T-T) |
-10 – 50 °C |
| Logistics data |
| Harmonized System (HS) code |
84713000 |
